ICAM IFT-15

DISCONTINUED

ICAM IFT-15

The ICAM IFT-15 by Xtralis is a micro bore aspirating smoke detection system with an alarm sensitivity range from 0.001% to 20% obscuration/m (0.0003% to 6.10% obscuration/ft). It is classified as a Very Early Warning Smoke Detector that can reliably detect fire at an early stage, and low to high concentrations of smoke over an area of 1,500 m2 (16,125 sq ft). It is configurable for a variety of environments and can identify immediately the actual sample point at the time of detection, enabling the fastest response.

FEATURES
APPLICATIONS
CERTIFICATIONS
ACCESSORIES
SERVICE & SUPPORT
  • 15 pipe addressable air sampling
  • 0.001% to 20% obscuration/m (0.0003% to 6.10% obscuration/ft)
  • 4 Alarms - Alert, Action, Fire 1, Fire 2
  • 15 x 50 m (15 x 164 ft) micro bore sampling pipe
  • Enhanced 0.7 bar rotary vane vacuum pump
  • Ethernet TCP/IP
  • RS232 and RS485 Modbus
  • 5 relay outputs and expandable optional relay module and 4 to 20 mA analog outputs module
  • Area coverage of up to 1,500 m2 (16,125 sq ft)

FEATURES
  • 15 pipe addressable air sampling
  • 0.001% to 20% obscuration/m (0.0003% to 6.10% obscuration/ft)
  • 4 Alarms - Alert, Action, Fire 1, Fire 2
  • 15 x 50 m (15 x 164 ft) micro bore sampling pipe
  • Enhanced 0.7 bar rotary vane vacuum pump
  • Ethernet TCP/IP
  • RS232 and RS485 Modbus
  • 5 relay outputs and expandable optional relay module and 4 to 20 mA analog outputs module
  • Area coverage of up to 1,500 m2 (16,125 sq ft)
APPLICATIONS

The detectors are configurable for a variety of environments, providing ideal fire detection solutions for:

  • Cabinets
  • EDP rooms
  • Elevators - hoistways, control rooms and lobbie
  • Prisons
  • Historic houses
  • Custody suites
  • Museums
  • Art galleries
CERTIFICATIONS
  • FM
  • UL
  • VdS
  • CFE
  • CE-EMC
  • CPR
  • CSFM
  • EN54-20
  • KFI
  • NF

If you would like a copy of the certificate, contact your local Sales Manager or visit the Xtralis Partner Extranet.

ACCESSORIES
SERVICE & SUPPORT

Please visit the Document Library for access to software, manuals, engineering specifications, application notes and other technical support documents.

RESOURCES

Download ICAM Product Line Brochure ICAM Product Line Brochure
Download Xtralis ICAM Elevator Code Compliance Flyer Xtralis ICAM Elevator Code Compliance Flyer


Product information is subject to change without notice. Product images may include options or accessories not included with the base model.
